Wood Wool Acoustic Panel

HERADESIGN Fine

Fine surface structure. Single layer magnesite-bonded wood wool acoustic panel - fibre width 2 mm.

Contact us

Show other regions

China

China

HERADESIGN® Fine

Beige (Natural tone 13)

600 x 600 mm

1200 x 600 mm

Edge detail 1

Edge detail 2

Colours

Let your imagination run wild with an almost unlimited range of colours from popular colour systems such as RAL, NCS or StoColor.

Technical specifications

Features

HERADESIGN® fine offering very good sound-absorbing properties due to HERADESIGN® wood wool tiles
Excellent sound absorption NRC 0.60
HERADESIGN ® fine A2 are available in fire resistance class A2 – s1, d0
This unique texture structure gives the tiles a noble and exclusive character for use in high-quality interior applications.

Application areas

Ideal for Office, Education, Commercial environments

Sound Absorption

NRC=0.60

Light Reflectance

~76% white (similar RAL 9010)
~60% natural color

Fire Reaction

A2-s1, d0
GB8624

Weight

19,0 kg/m2 (25 mm)

Thermal Conductivity

λ = 0.090 W/m K

Humidity Resistance

RH90

VOC

A+

Formaldehyde

E1

Recycled Content

17 - 25%

Impact Resistance

Class 1A / EN13964 and DIN 18032

Certification

INSTITUTE FOR BIOLOGICAL BUILDING PRODUCTS

The purpose of IBR, a German environmental testing agency for building materials, is to recommend healthy and environmentally friendly construction products to consumers and affix certification labels on their product packages. The logo was founded in 1982 to give consumers with health and environmental awareness the opportunity to protect their living environment from being injured by healthy building materials and equipment. IBR is testing products related to human health and has its own inspection seal for more than 30 years.

View website

ENVIRONMENTAL PRODUCT DECLARATION

EPD are independently verified and registered documents that communicate transparent and comparable information about the life-cycle environmental impact of products.

BLUE ANGEL

The Blue Angel ecolabel is awarded by an independent Jury to environmentally friendly products. Each label specifies that the product meets a list of criteria considering environmental and health-related aspects.

View website

PAN EUROPEAN FOREST CERTIFICATION

PEFC was founded in 1999 in response to the specific requirements of small- and family forest owners that had been unable to achieve forest certification through alternative certification systems.

Since then, we have grown to become the world’s largest forest certification system and the certification system of choice for small-forest owners.

View website

EMISSIONS IN INDOOR AIR

A + is the symbol with the highest environmental protection level in French VOC label. É missions dans l'air int é rieur, corresponding to emissions in indoor air in English and "emissions in indoor air" in Chinese.

French VOC label is a mandatory environmental protection label for indoor buildings to enter the French market.

FOREST STEWARDSHIP COUNCIL

Forest Management Committee, which advocates voluntary, independent and third-party certification as the main method and means. The certification of each country is based on 10 general guidelines and forest evaluation standards, mainly including social, environmental and economic factors. Forest managers and evaluators are certified based on these factors. The FSC forest certification process requires 10 guidelines and standards suitable for each country.

EUROFINS

Eurofins Scientific is a group of international life sciences companies which provide a unique range of analytical testing services to clients across multiple industries.

View website

HERADESIGN® Fine Datasheet (CN)

pdf | 5 MB
